Yamaha Digital Dante PA DJ Equipment. Boxed

Description

Yamaha DM-3 Mixer with Dante. (Open-Box Mint) £1650 (List 1995)

Yamaha Tio1608-D2 Dante Stage Box Digital Snake (Open-Box Mint) £1295 (List £2015)

Yamaha DZR315-D (Open-Box Mint) £1850 (List £2696)

Yamaha DZR315-D (Open-Box Mint) £1850 (List £2696)

Yamaha DXS18-XLF-D (Open-Box Mint) £1850 (List £2429)

Yamaha DXS18-XLF-D (Open-Box Mint) £1850 (List £2429)

Some road-cases available. Mint. (They're in storage but I can get them)

I will include an EtherCON network cable per speaker/mixer etc.

If someone wants the whole system (£10,750) I will included all the power leads, Ethernet & EtherCON cables and a pre-configured Cisco Catalyst network switch to run the Dante network with 100 mile Delivery.

I could probably deliver to most places in Northern Ireland if you do a bank transfer.

Yamaha DZR315 Powered PA Speaker 2000W

Yamaha Music London List Price £2696

Dynamic Power Handling, 15inch; LF Driver & 8inch; MF Driver
The DZR315 is 3-way bi-amped powered loudspeaker and is the most powerful model in the DZR Series producing a maximum 143dB SPL with supreme clarity. Best-in-class SPL performance, sophisticated DSP processing, unrivaled low-frequency sound reproduction - the DZR315 delivers on all fronts realising a truly professional sound delivered with a level of power that belies its compact, lightweight design. Ideal for use in a front of house main PA, it also includes integrated M10 rigging points for suspended applications.
3-way powered loudspeaker with a 2inch HF, an 8inch MF and a 15inch; LF
Maximum 143dB SPL and 31Hz-20kHz frequency range is ideal for FOH main PA
High power 2000W Class-D amplifier module
96kHz DSP and FIR filter for true high-resolution sound with super low latency
Features Advanced FIR-X tuning, the combination of FIR filtering and correct EQ for minimizing phase distortion
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
D-Contour and highly reliable protection circuits
Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
Perfectly suited for use with DZR full-range speakers, the DXS18XLF-D is a Dante-equipped powered bass-reflex type subwoofer with extended low frequency, producing a best-in class maximum SPL of 136dB SPL with superb clarity and power.


Yamaha DXS18XLF-D Dante-Equipped Powered PA Subwoofer

Yamaha Music London List Price £2429

1600W Dynamic Power Handling, 18" WooferPowered 18” subwoofer with 4” Voice Coil
Maximum 136dB SPL and 30Hz-150Hz frequency range is ideal for today’s sound engineering demands
High power 1600W Class-D amplifier module
96kHz DSP for true high-resolution sound with super low latency
Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility
Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display
Equipped with D-XSUB processing and cardioid mode capability
Lightweight yet very durable plywood cabinet with premium grade Polyurea coating
Optional speaker cover (SPCVR-DXS18X) and wheel kit (SPW-1)


Yamaha DM3 (with Dante) Compact Digital Mixer

Yamaha Music London List Price £1995

Yamaha DM3 (with DANTE) Digital Mixer
RAISING THE BAR FOR COMPACT DIGITAL MIXERS.

DM3 Series allow engineers to capture the on-stage sound accurately, without coloration, and then add creative touch as required. It exemplifies a “less is more” design philosophy, utilizing a 9” touchscreen and a single Touch & Turn knob for managing most of the console’s operations. DM3 mixing consoles give you the power and flexibility to DO MORE than ever imagined with a digital console this compact.

INPUT MIX: 16 MONO + 1 ST + 2FX
BUS: 6 MIX + 2 FX + 2 MATRIX
9 MOTOR FADERS, 1 TOUCH & TURN
ANALOG IN: 16 MIC/LINE
ANALOG OUT: 8 (XLR)
18 X 18 AUDIO INTERFACE VIA USB
2 FX & GEQ ON MIX/STEREO BUS
16 IN/16 OUT DANTE INTERFACE (DM3)
DAW REMOTE (HUI)
CUBASE AI & VST RACK ELEMENTS

Yamaha TIO1608-D2 DANTE enabled I/O rack

Yamaha Music London. List Price £2015

The Tio1608-D2 is a Dante-equipped I/O rack with 16 microphone/ line inputs and 8 line outputs.
Simple, versatile, high-definition Dante Stagebox
The Tio1608-D2 is a Dante-compatible I/O rack equipped with 16 mic/line inputs and 8 line outputs. It can control gain from TF Series and DM3 consoles remotely, allowing the construction of a simple stagebox system. The versatile Tio1608-D2 also supports 96k, making it perfect for use as an I/O rack in large installations with products such as the RIVAGE PM or DME7.
The versatility and scalability of Dante
The Dante audio network standard is utilized in the DM3 and TF series, as well as in the CL and QL digital mixers. These consoles can be freely combined with the Tio1608-D2 or an R series I/O rack to create a system that matches the required scale and budget. Patching can be enabled via “Dante Controller” while Remote HA can be controlled by “R Remote” software.
