2007 Genie Z-45/25 4WD

Description

Everything working as it should
6 months Loler & GA1 certs
Price £15,000+vat

Measurements US Metric
Working height max.(1) 51 ft 6 in 15.86 m
Platform height max. 45 ft 6 in 13.86m
Horizontal reach max. 24 ft 8 in 7.52 m
Up and over clearance max. 23 ft 7 in 7.14 m
A Platform length 2 ft 6 in 0.76 m
B Platform width 6 ft 1.83 m
C Height - stowed 7 ft 2.13 m
D Length - stowed 21 ft 10 in 6.65 m
E Width 7 ft 6 in 2.29 m
F Wheelbase 6 ft 8 in 2.03 m
G Ground clearance - center 1 ft 3 in 0.37 m

Productivity
Lift capacity max. - unrestricted 500 lb 227 kg
Platform rotation 160°
Jib length 5 ft 1.52 m
Vertical jib rotation 135°
Turntable rotation 355°
Turntable tailswing 0 in 0 cm
Drive speed - stowed(2) 3.1 mph 5 km/h
Drive speed - raised 0.68 mph 1.1 km/h
Gradeability - stowed(2) 45 %
Tilt sensor activation (front to back/side to side) 2.5°- 4.5° / 4.5°
Turning radius - inside/outside 5 ft 6 in / 14 ft 9 in 1.68 m / 4.50 m
Tires (solid, non-marking) 315 / 55 D20

Power
Power Diesel
Auxiliary power unit 12 V DC
Hydraulic tank capacity 22 gal 83 L
Fuel tank capacity 17 gal 64 L
Weight(3) and Floor Loading(4)
Weight 14,363 lb 6,515 kg
Tire contact pressure 60 psi 414 kPa
Occupied floor pressure (tires) 190 psf 9.12 kPa

Sound and Vibration Levels
Sound Pressure level (ground workstation) 87 dBA
Sound Pressure level (platform workstation) 82 dBA
Vibrations 8 ft 2 in/s² 2.5 m/s2
