TSC Direct Thermal label printer USB

Description

Printing
Print technology
Indicates the method used to print by this product.
Direct thermal
Colour
The main colour of the product.

Maximum resolution
Maximum printing resolution.
203 x 203 DPI
Number of printable dots 8 dot
Print speed
The maximum speed at which a printer can print.
152.4 mm/sec
Printing colours
The colours that can be produced by the printer.
Black
Maximum printing width
The maximum width of the image that can be printed.
10.8 cm
Rotated printing
Paper handling
Maximum label length 2794 m
Maximum roll diameter
The maximum size of roll that can be used, measured by the diameter which is the distance from one side to the other with a straight line passing through the centre of the roll.
12.7 cm
Media thickness 0.055 - 0.19 mm
Supported paper width 19 - 114 mm
Maximum media length 2.79 m
Ports & interfaces
Connectivity technology
The technology that enables connectivity of the device, e.g. wired or wireless.
Wired
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.

Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.

USB port
The device features a socket into which a USB cable can be plugged.

Optional connectivity Bluetooth
Performance
Page description languages TSPL-EZ
Internal memory
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
16 MB
Flash memory 8 MB
Built-in barcodes AZTECCODE, Code 11, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in processor
Whether or not a processor is built into the device.

Certification FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC
Design
Product colour
The colour e.g. red, blue, green, black, white.
Black
Built-in display
A display which is part of the product, so you do not need to attach another display.

Display
The description of display that can includes display type, resolution, size etc.

Power
AC input voltage
The voltage of the AC electricity that is inputted into the product.
100 - 240 V
AC input frequency 50/60 Hz
AC adapter output voltage 24 V
AC adapter output current 2.5 A
Power source type
What the power source is.
AC
Operational conditions
Operating relative humidity (H-H) 25 - 85%
Storage relative humidity (H-H) 10 - 90%
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
5 - 40 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-40 - 60 °C
Weight & dimensions
Width
The measurement or extent of something from side to side.
172 mm
Depth
The distance from the front to the back of something.
195 mm
Height
The measurement of the product from head to foot or from base to top.
165 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
1.5 kg
Packaging content
Cables included AC, USB
Technical details
Sustainability certificates ENERGY STAR
Compliance certificates BIS, CB, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC), RCM, UL
